SYSTEM OVERVIEW
The ClydeHSI microscope scanner is a unique multi-modal capable instrument that permits both light and dark field microscopy, transmission miscroscopy, as well as luminescence and polarisation studies for sample bi-refringence.
The system has a motorised nosepiece for ease of use, with wide spectral range objectives as well as automatic mode change facilities. Robotic auto-loader allows automatic high-resolution scanning of up to 6 A4 sized samples in one session - no user monitoring required.
The system offers versatility and high precision, operating within the 400 - 1700 nm spectral range with spatial resolution ≤1 μm - ideal for applications with colour and materials identification needs.
TECHNICAL SPECIFICATIONS
| Parameter | Value | Units | Comment |
|---|---|---|---|
| Operational Modes | Reflectance, Transmission, Luminescence, Raman, Polarisation | - | Multi-modal operation with spectral correction and multi-strip mosaic imaging for large area high resolution scans |
| Spectral Range | 400 to 1700 | nm | Broad spectral range idel for colour and materials identifications needs |
| Spatial Resolution | ≤1 | µm | Interchangeable objectives using motorised nosepiece |
| Spatial Range | 300 x 300 | mm2 | Large area highly stabilised motorised platform |
| Stage Repeatability | ≤1 | µm | |
| Max Sample Area | 300 x 300 | mm2 | Depends upon stage choice: consult ClydeHSI |
| Optional Auto-loader Sample Capacity | 6 | Robotic arm loads samples into sample area automatically |
