ROTACIÓN SISTEMA DE ESCANEO
Quick and easy set up with 360 degree hyperspectral scanning capability - ideal for scanning large scenes in difficult locations quickly and effectively.
Fully compatible with all of our
hyperspectral cameras and fully operated - by both experienced and new users - through our unique
spectraSENS software.
RESUMEN DEL SISTEMA
El sistema de escaneo por rotación de ClydeHSI es la solución de escaneo ideal para escenas muy grandes que necesitan escanearse rápidamente, para usar con objetivos de telefoto, o con cámaras hiperespectrales UV donde otros tipos de escáner pueden no ser apropiados.
Incluye un sensor de referencia cero y se puede utilizar en los modos de exploración horizontal o vertical.
Compatible con todas las configuraciones de cámaras hiperespectrales, incluidas las de una sola cámara y los sistemas VNIR y SWIR duales.
Compacto, rápido y fácil de configurar e ideal para realizar mediciones en lugares considerados "difíciles".
El FOV y el IFOV se calculan automáticamente para la lente del objetivo en uso y esto permite que la función de píxeles cuadrados automáticos establezca las velocidades de rotación de escaneo de manera adecuada y se sincronice con las velocidades de cuadro de la cámara espectral.
ESPECIFICACIONES TÉCNICAS
| Parámetro | Valor | Comentario | |
|---|---|---|---|
| Ángulo de rotación | 360 | ||
| Resolución angular | ≤0,005 | ||
| Velocidad de escaneo angular | ≤25 | Consulte con ClydeHSI para obtener velocidades de escaneo más altas | |
| - | Adaptador | ||
| Montaje | 3/8 o 1/4 " | - | Se adapta a todos los sistemas de trípode que utilizan soportes de cámara estándar |
| Interfaz | USB | - | Compatible con USB, adaptadores disponibles para RS 232 y RS 422/485 |
| Energía | 24 | V CC | Con protección contra polaridad inversa, fuente de alimentación suministrada, paquetes de baterías recargables disponibles |
